SIDE COVER
0
4TL1/4TL2
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1A | 36LF171101H6 | SIDE COVER-1LH(MAROON) | ₹ 507 | 1 | CNM | |
| 1B | 4TLF17107000 | SIDE COVER L.H (VRC) | ₹ 374 | 2 | VRC | |
| 1C | 4TLF171070H9 | 4TLF171070H9 | ₹ 0 | 1 | YB | |
| 2 | 904801205300 | 904801205300 | ₹ 0 | 1 | ||
| 3 | 90201065F300 | 90201065F300 | ₹ 0 | 1 | ||
| 4 | 901460600900 | SCREW SLOTTED | ₹ 10 | 1 | ||
| 5 | 901790626400 | 901790626400 | ₹ 0 | 1 | ||
| 6A | 4TLF172070H6 | 4TLF172070H6 | ₹ 0 | 1 | CNM | |
| 6B | 4TLF17207000 | SIDE COVER R.H (VRC) | ₹ 374 | 1 | VRC | |
| 6C | 4TLF172070H9 | 4TLF172070H9 | ₹ 0 | 1 | YB | |
| 7 | 904801205300 | 904801205300 | ₹ 0 | 2 | ||
| 8 | 90201065F300 | 90201065F300 | ₹ 0 | 1 | ||
| 9 | 950220601600 | BOLT, FLANGE | ₹ 11 | 1 | ||
| 10 | 4TLF17810000 | 4TLF17810000 | ₹ 0 | 1 | ||
| 11 | 901830404700 | NUT SPRING | ₹ 6 | 3 | ||
| 12 | 4TLF17821000 | 4TLF17821000 | ₹ 0 | 2 | ||
| 13 | 901830404700 | NUT SPRING | ₹ 6 | 3 | ||
| 14 | 36LF17830000 | EMBLEM 3 LH | ₹ 135 | 1 | ||
| 15 | 901830601800 | NUT SPRING | ₹ 7 | 2 | ||
| 16 | 36LF17840000 | EMBLEM 4 RH | ₹ 135 | 1 | ||
| 17 | 901830601800 | NUT SPRING | ₹ 7 | 2 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - YAMAHA 4TL1 RX 135 4 GEAR Series SIDE COVER
