SIDE COVER
0
4TL4
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1A | 4TLF17100000 | SIDE COVER ASSY LH CNM | ₹ 340 | 1 | FOR CNM | |
| 1B | 4TLF17101000 | 4TLF17101000 | ₹ 0 | 1 | FOR BG | |
| 1C | 4TLF17102000 | 4TLF17102000 | ₹ 0 | 1 | FOR VDB | |
| 2 | 904801205300 | 904801205300 | ₹ 0 | 2 | ||
| 3 | 902010638000 | WASHER PLAIN | ₹ 3 | 1 | ||
| 4 | 901460600900 | SCREW SLOTTED | ₹ 10 | 1 | ||
| 5 | 901790626400 | 901790626400 | ₹ 0 | 1 | ||
| 6A | 4TLF17200000 | SIDE COVER ASSY 2 CNM | ₹ 340 | 1 | FOR CNM | |
| 6B | 4TLF17201000 | 4TLF17201000 | ₹ 0 | 1 | FOR BG | |
| 6C | 4TLF17202000 | 4TLF17202000 | ₹ 0 | 1 | FOR VDB | |
| 7 | 904801205300 | 904801205300 | ₹ 0 | 2 | ||
| 8 | 902010638000 | WASHER PLAIN | ₹ 3 | 1 | ||
| 9 | 950220601600 | BOLT, FLANGE | ₹ 11 | 1 | ||
| 10 | 4TLF17810000 | 4TLF17810000 | ₹ 0 | 1 | ||
| 11 | 901830404700 | NUT SPRING | ₹ 6 | 3 | ||
| 12 | 4TLF17821000 | 4TLF17821000 | ₹ 0 | 1 | ||
| 13 | 901830404700 | NUT SPRING | ₹ 6 | 3 | ||
| 14 | 36LF17830000 | EMBLEM 3 LH | ₹ 135 | 1 | ||
| 15 | 901830601800 | NUT SPRING | ₹ 7 | 2 | ||
| 16 | 36LF17840000 | EMBLEM 4 RH | ₹ 135 | 1 | ||
| 17 | 901830601800 | NUT SPRING | ₹ 7 | 2 | ||
| 18 | 901190684300 | BOLT WITH WASHER | ₹ 4 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - YAMAHA 4TL4 RX 135 5 SPEED Series SIDE COVER
