SIDE COVER
0
5US1
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1A | 5USF1710100X | SIDE COVER ASSY 1 (MAROON) | ₹ 345 | 1 | FOR CNM | |
| 1B | 5USF1710200X | SIDE COVER ASSY 1 -LYNM | ₹ 345 | 1 | FOR LYNM9 | |
| 1C | 5USF1710500X | SIDE COVER ASSY 1 (BG) | ₹ 360 | 1 | FOR BG | |
| 2A | 5USF1720100X | SIDE COVER ASSY 2 (CNM) | ₹ 380 | 1 | FOR CNM | |
| 2B | 5USF1720200X | SIDE COVER 2 (LYNM9) | ₹ 345 | 1 | FOR LYNM9 | |
| 2C | 5USXF172500X | SIDE COVER ASSY 2 ( BG ) | ₹ 396 | 1 | FOR BG | |
| 3 | 5USF17310000 | COVER SIDE 3 SILVER | ₹ 117 | 1 | ||
| 4 | 901500602100 | SCREW CROSS ACCESSED RO | ₹ 45 | 6 | ||
| 5 | 904801386100 | GROMMET | ₹ 8 | 2 | ||
| 6 | 2YAWF1780100 | LOCK WITH KEY( COVER SIDE 1-LH | ₹ 195 | 1 | ||
| 7 | 904802418600 | GROMMET | ₹ 8 | 1 | ||
| 8 | 90201225A400 | WASHER PLAIN | ₹ 3 | 1 | ||
| 9 | 5USF177G0000 | BATTERY BOX | ₹ 75 | 1 | ||
| 10 | 901190611700 | BOLT WITH WASHER | ₹ 23 | 3 | ||
| 11 | 5USF173B0000 | EMBLEM 3D L.H | ₹ 137 | 1 | ||
| 12 | 5USF174B0000 | EMBLEM 3D R.H | ₹ 137 | 1 | ||
| 13 | 901792280000 | NUT | ₹ 9 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - YAMAHA 5US1 ENTICER Series SIDE COVER
