SIDE COVER
0
5YY4
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1A | 5YYF1710B000 | SIDE COVER 1(LH)DRMK | ₹ 448 | 1 | FOR DRMK | |
| 1B | 5YYF1710C000 | 5YYF1710C000 | ₹ 0 | 1 | FOR DPBML | |
| 1C | 5YYXF171000Y | SIDE COVER ASSY 1 (SL -3) | ₹ 545 | 1 | FOR SL03 | |
| 2A | 5YYF1720B000 | SIDE COVER 2(RH)DRMK | ₹ 448 | 1 | FOR DRMK | |
| 2B | 5YYF1720C000 | 5YYF1720C000 | ₹ 0 | 1 | FOR DPBML | |
| 2C | 5YYF1720D000 | SIDE COVER 2(RH)SL-3 | ₹ 493 | 1 | FOR SL03 | |
| 3 | 904801386100 | GROMMET | ₹ 8 | 2 | ||
| 4 | 5YYF17780000 | DAMPER LOCATING | ₹ 3 | 2 | ||
| 5 | 2YAWF1780100 | LOCK WITH KEY( COVER SIDE 1-LH | ₹ 195 | 1 | ||
| 6 | 901702218700 | NUT | ₹ 20 | 1 | ||
| 7 | 904802418600 | GROMMET | ₹ 8 | 1 | ||
| 8 | 90201225A400 | WASHER PLAIN | ₹ 3 | 1 | ||
| 9 | 901590608700 | 901590608700 | ₹ 0 | 1 | ||
| 10 | 5YYF177G0000 | BOX BATTERY | ₹ 94 | 1 | ||
| 11 | 901190611400 | BOLT WITH WASHER | ₹ 15 | 3 | ||
| 12 | 5YYH21290000 | COVER BATTERY | ₹ 21 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - YAMAHA 5YY4 FAZER DISC Series SIDE COVER
